VIBE British Audio POWERBOX80.6-8DSP-V3 | 6-Channel 1200W Class D Amplifier with Integrated 8-Channel DSP

BRITISH ENGINEERING & UNMATCHED AUDIO CONTROL

The VIBE POWERBOX80.6-8DSP-V3 is the ultimate solution for high-fidelity car audio in a compact package. This 6-channel Class D amplifier features an integrated 8-channel Digital Signal Processor (DSP), giving you the power to amplify your speakers while professionally tuning your entire soundstage via your smartphone.

VERSATILE SYSTEM CONFIGURATIONS:

- Active 2-Way Front + Rear: Run a 2-way active front stage (Tweeters and Woofers) plus rear fill speakers with full DSP control.

- Active 3-Way Front: Perfect for audiophiles running a dedicated 3-way active front setup (Tweeter, Mid-range, Woofer) for perfect imaging.

- High-Power 2.1 System: Bridge channels 5 and 6 to power a subwoofer while driving high-quality front components.

- Euro Car Specialist: Specifically designed for BMW, Mercedes-Benz, Audi, and VW models that require multi-channel amplification for factory upgrades.

- Stealth Installations: Its micro-footprint allows for hidden mounting under seats or behind dashboards, maintaining a clean factory look.

KEY FEATURES:

- Massive 6-Channel Power: 6 x 80W RMS @ 4

 (up to 1200W Max).

- Integrated 8-Channel DSP: 6 amplified channels + 2 additional pre-outs for an extra external amplifier (like a dedicated Monoblock).

- Smartphone App Tuning: Fully customize your sound via Bluetooth using the VIBE DSP app (iOS & Android). Adjust EQ, Time Alignment, and Crossovers in real-time.

- Optical TOSLINK Input: Direct digital connection for the cleanest possible audio signal.

- Autosense Technology: Automatically powers on/off via high-level signal—no remote turn-on wire required for most modern cars.

INSTALLATION & WIRING REQUIREMENTS:

Power & Ground Cable: Minimum 8 Gauge (8AWG); 4 Gauge (4AWG) is highly recommended.

Fuse Rating: 60A (Internal and inline battery fuse).

Grounding: Must be connected to a clean, bare-metal chassis point with the shortest cable possible.

Mounting: Do not mount upside down to ensure proper heat dissipation.

TECHNICAL SPECIFICATIONS:

RMS Power @ 4 : 6 x 80 Watts

RMS Power @ 2 : 6 x 100 Watts

Bridged Power @ 4 : 4 x 80W + 1 x 200W (Note: Only Channels 5 & 6 are bridgeable)

Dimensions (H x W x D): 40mm x 220mm x 131mm

Operating Voltage: 9.6V – 18V

EQ: 31-Band Parametric with variable Q-factor

WHY CHOOSE VIBE?

Designed and engineered in England, the PowerBox series delivers the signature "British Audio" warmth and precision. It is the perfect choice for owners of modern vehicles looking for a massive sound upgrade without modifying the vehicle's interior.

WHAT’S IN THE BOX?

1 x POWERBOX80.6-8DSP-V3 Amplifier

Owner's Manual

High-level input wiring harness
