Alpine RS-W10D2 R-Series shallow-mount 10" subwoofer with dual 2-ohm voice coils

Shallow-mount upgrade

Alpine's R-Series subwoofers are known for their high power handling and tight response. The new RS-W10D2 shallow-mount sub delivers the same quality in a speaker that'll fit where other subs won't.

Small size, big impact

Built around a solid, cast-aluminum frame, this shallow sub requires a mounting depth of only 3.271 inches. Yet the RS-W10D2's cone excursion is the same as a regular R-Series sub, so you'll enjoy the kind of impact you expect from Alpine.

Fits into your system

This versatile sub sounds great in sealed or ported enclosures. You can wire the dual voice coils for either 1- or 4-ohm total impedance, giving you more wiring options when setting up your system. The sub handles up to 600 watts RMS (1800 watts peak) so make sure you've got a solid amp to power it. Grille sold separately.

10" shallow-mount subwoofer with dual 2-ohm voice coils

polypropylene cone with aluminum dust cap and butyl rubber surround

cast aluminum frame

frequency response: 25-100 Hz

power handling: 600 watts RMS (300 watts per coil)

peak power: 1800 watts

sensitivity: 79 dB

top-mount depth: 3.271"

sealed box volume: 0.49-1.04 cu. ft.

grille not included

warranty: 1 year

Size : 10 -inch

Impedance (Ohms) : 1, 4

Cone Material : Polypropylene

Surround Material : Rubber

Free-Air No

Dual Voice Coil : Yes

Sensitivity : 79 dB at 1 watt

Frequency Response : 25 - 100 Hz

Max RMS Power Handling : 600

Peak Power Handling (Watts) : 1800

Top Mount Depth (inches) : 3 5/16

Bottom Mount Depth (inches) : 3 5/8

Cutout Diameter or Length (inches) : 9 5/8

Vas (liters) : 20.64

Fs (Hz) : 30

Qts : 0.95

Xmax (millimeters) : 20
