ALPINE S2-S65C Next-Generation S-Series 6.5"inch 2-Way component speaker system
Newly redesigned and Hi-Res Audio Certified, the Next-Generation S-Series S2-S65C 16.5cm (6-1/2") Component Speakers offer a new standard in entry-level sound performance.
We packed supreme capability into these speakers by using highly effective materials and proprietary design elements. The lightweight woofer cone, crafted from a combination of polypropylene, glass fiber, and mica materials, serves up the essential high output / low distortion sound required for High-Res Audio performance. Alpine S-Series speakers feature increased magnet sizes for more power handling and best mid-bass performance in their category.
The woofer's High Amplitude Multi-Roll (HAMR) surround brings out the best in bass by allowing maximum cone movement. A 2.5cm (1") dome tweeter serves up all the high-frequency detail you've been missing with your factory speakers.
All speakers in the S-Series line have a wide vehicle fitment range and include several adapters and spacers. Using in-line crossovers, these speakers can be installed quick and easy even at home.
Alpine S-Series speakers are available in coaxial and component configurations and come in a variety of different sizes, such as 20cm, 16,5cm, 13cm, 10cm, 6x9 inches and 6x8 inches.
FEATURES
General
Woofer Size: 16.5cm (6-1/2")
2.5cm (1“) Tweeters with Swivel Housing
Hi-Res Audio Certified (up to 40kHz)
Poly Propylene, Glass Fiber, and Mica Cone Material
Lightweight Design with High Output and Low Distortion
High-Amplitude Multi-Roll (HAMR) Surround
Compatible with KTE-S65G Speaker Grills (sold separately)
SPECIFICATIONS
Power Handling
Peak Power: 240 Watts
RMS Power: 80 Watts
Dimensions Woofer
Cutout Diameter (flush-mount): 128mm
Mounting Depth: 57.7mm
Mounting Height: 12.0mm
Magnet: 90.0mm
Dimensions Tweeter
Cutout Diameter (flush-mount): 51mm
Mounting Depth: 17.6mm
Mounting Height: 8mm
General
Frequency Range: 55 Hz - 40 kHz (Hi-Res Audio Certified)
Impedance: 4 Ohms
Sensitivity: 88 dB/W
