BLAUPUNKT MPD 10810A Velocity Power Series 8-Ch High / 2-Ch Low Level Inputs | 8-Ch High / 10-Ch Low Level Outputs

AudioDSP RMS Power : 50W x 8(4Ω)

DSP Resolution : 24Bit

DSP Power : 240MHz

DSP Output Power RMS @ 4 Ohms (≤10% THD) : 65Wx8

Distortion (THD) : ≤0.8%

Operating Voltage : 10 -17V

Sampling Rate : 44.1kHz/16Bit

Signal Converter A/D : MS5358

Signal Converter D/A : MS4344

Input

2 x RCA/ Aux-in

8 x High Level Speaker Input

1 x Optical SDPIF

1 x USB Flah Drive

RCA/Cinch Sensitivity : 0.75V

High Level Input Sensitivity : 6.8V

Low Level Input Impedance : 15k Ohms

High Level Input Impedance : 4.7 Ohms

S/N Ratio Digital-in : ≥93dB

S/N Ratio Analog-in : ≥93dB

Output

10 x RCA/Cinch

8 x High Level Speaker Output

Output Voltage : 14.1V

Feature

Class D Amplifier

Max. Output Power : 520W

Frequency Response : 20Hz-20kHz

Max. Current Consumption : 40A

Dimension (W x H x D): 198 x 182 x 45mm

Weight: 1.48kg
