Blaupunkt VELOCITY POWER DSP WITH CLASS D AMPLIFIER MPD 11212AH 12-CH High Level Inputs

MPD 11212 AH Specification

Audio

RMS Power : 50W x 10 + 100W x 2 at 4ohm

Max. Output Power @ 4 Ohms (≤10% THD +N) : 100W x 10 + 200W x 2

DSP Resolution : 24 Bit

DSP Power : 96kHz

Distortion (THD) : < 0.05%

Damping Factor : > 70

Operating Voltage : 9V -17V

Sampling Rate : 96kHz

Signal Converter A/D : PCM1840

Signal Converter D/A : PCM1681

RCA/Cinch Input Sensitivity : 6.5Vpp

Input

6 x Low Level RCA Input

1 x Coaxial Input

12 x High Level Speaker Inputs

1 x USB input

1 x Optical SPDIF Input

Impedance High Level : 4.7 ohms

Impedance Low Level : 10k ohms

Output

12 x RCA/ Cinch Output

12 x High Level Speaker Outputs

Voltage RCA/Cinch : 6.5Vpp

Feature

Class D Amplifier

Max. Output Power : 1400W

Frequency Response : 20Hz-40kHz

Max. Current Consumption : 50A

Dimension (W x H x D) : 242 x 194.6 x 47mm

BT Dongle

Remote Control
