DLS Signature Series S2 - Class A/B 2 Channel Amplifier 110W RMS X 2
The S2 is a 2-channel amplifier. Can be used for a pair of stereo speakers or a subwoofer connected inmono bridge mode
Silence is Golden
A truly great amplifier does not make any sound at all. The Signature series has unrivalled low distortion and an extremely high signal-to-noise ratio, letting you hear only music and experience new details in your favourite songs with a warm clarity and a firm mid bass with impressive authority.
Optimised for perfection
No detail has been left untweaked, from the custom cooling system to the power supply.We have even trimmed each channel individually and synchronised every component with each other to perform in perfect harmony.
When used together with a Digital Sound Processor there is an option to bypass all preamp circuitry, letting the DSP get complete control of all sound tuning parameters. This allows a clean and unaltered signal to reach the amplifying stage in full without sonic degradation.
Enjoy music in full, unaltered and perfect, with the Signature series.
-
Number of channels – 2
-
Amplifier cl – AB
-
Output power in 2 ohm – 2 x 180 Watt
-
Output power in 4 ohm – 2 x 110 Watt
-
Output power in 4 ohm bridged – 1 x 360 Watt
-
Damping factor 150
-
THD at 3W, 20Hz-20kHz 0,019%THD at 100W, 1kHz 0,02%
-
S/N ratio, A-weighted 116 dB
-
Frequency range 10 Hz – 50 kHz
-
Input sensitivity 1 – 4 Volt
-
Input impedance, low level 6 kohm
-
Input impedance, high level 45 ohm
-
Filter low p 50-500 HzFilter high p 50-500 Hz
-
Power consumption (idle) 0,5 A
