Infinity Kappa Four - Class D - 4 Channel Full Range car amplifier — 100 watts RMS x 4
Engineered For The Ultimate Sound Experience
Kappa full-range, multi-channel amplifiers deliver the efficiency and power you expect from Class D amplifiers –and the performance you expect from Infinity. The comprehensive all new E.A.R.L terminal enables easy installation and optimized performance. The industrial design not only provides an elegant look, but also enhances power dissipation to ensure long term reliability. Kappa amplifiers give you power to shape your car audio experience in new ways.
Class D Design
Every Kappa amplifier, including the full-range models, features high-efficiency Class D topology. This technology allows Infinity to engineer amplifiers that are more compact, generate less heat, and draw less current from the vehicle’s electrical system.
Low Distortion Infinity’s Kappa amplifiers have been engineered to deliver the lowest distortion possible, enhancing the audio experience regardless of output level.
Full On-Board Protection
Infinity Kappa amplifiers have on-board circuitry to protect from shorts, temperature, overvoltage and undervoltage. An LED indicator is included on all five models to let the user know when one of these conditions exists.
Proprietary High-Conductivity Terminals All Infinity Kappa amplifiers equipped with newly introduced E.A.R.L terminal for better grounding.
Compact footprint With it becoming more and more difficult to find spacious locations for amplifier mounting, Infinity Kappa amplifiers have been developed in a small compact form factor to allow more location versatility.
Sleek design Sometimes, an amp can be as stylish as it is powerful. With anodized aluminum and screwdriver access concealed by a magnetically attached panel, Infinity Kappa amplifiers have a clean, streamlined industrial design.
Full-Range Line Outputs The full-range Kappa amplifiers include full-range line outputs. This allows the audio signal to be routed to additional amplifiers or self-powered subwoofer solutions, increasing your system configuration option.
Technical Specifications:
● Operating voltage 9-16 volts
● RMS power @ 4 ohms 100W x 4
● RMS power @ 2 ohms 120W x 4
● RMS bridged power @ 4 ohms 240W x 2
● Total peak power 1500W
● Frequency response 15Hz – 35kHz@-3dB
● Crossover filter LPF/HPF 32Hz – 320Hz
● Variable 12dB/Oct
● THD + N at rated power ≤0.1%
● High input maximum signal level 20V
● High input maximum sensitivity 2V
● Line input maximum signal level 2V
● Line input maximum sensitivity 0.2V
● Line-in signal-to-noise ratio (reference to 1 watt) ≥80dB
● Quiescent current draw ≤1.6A
● Fuse size 2 x 30A
● Dimensions (H x W x D) 43 x 177 x 260mm
● Weight 2.57kg
