JBL Stage 2 Bundle - Clear Voice Upgrade (Free Installation Kits)

JBL STAGE 2 SERIES + NAKAMICHI 6 CHANNEL DSP

FREE SPEAKER ADAPTER AND SOCKET

Speaker Kit

*Honda - all models with 6/6.5" speakers *except latest generation civic / crv (2024 and above)

*Toyota - all models with 6/6.5inch speaker and Alza new gen (dash speaker 4pin socket not included)

please pm for corolla and vios models

MODEL: Stage2 65CF – 6.5″ 2-Way Component Set

Peak Power Handling: 720 W

RMS Power Handling: 90 W

Sensitivity: 90 dB

Frequency Response: 60 Hz – 20 kHz

Impedance: 4 Ohms

Woofer Size: 6.5″ (16.62 cm)

Installation Depth: 6.06 cm

MODEL: Stage2 65F – 6.5″ 2-Way Coaxial

Peak Power Handling: 480 W

RMS Power Handling: 60 W

Sensitivity: 90 dB

Frequency Response: 55 Hz – 20 kHz

Impedance: 4 Ohms

Installation Depth: 6.8 cm

Design: 2-Way coaxial (woofer + tweeter), grille-less.

Woofer Size: 6.5″ (16.62 cm)

MODEL: NAKAMICHI NDSK4165AU

Dynamic Range(RCA Input): ≥100dB

S/N(RCA Input): ≥90dB

Frequency Response: 20Hz~20KHz

Input Impedance High Level Input: 240Ω

Low level Output Impedeance: ≤100Ω

Signal Input RCA Input: 8Vpp; High Level: 26Vpp

Output Range RCA Output: 12Vpp; Amplifier: 4×60W

Power DC: 9V-16V

REM Input High Level Input Signal: FL+/ FL- or ACC control cable

REM Output: +12V Startup Voltage Output

Standby Power: ≤0.1W

Gross Weight Approximately: 0.7kg

Box Dimension (L×H×W): 174.5×120×40mm
