Phoenix Gold ZDA4.8 - ZD Series 8 Channel Car DSP with 4 Channel Built-In Amplifier

6IN - 8OUT | 31BAND EQ | 8CHANNEL DSP WITH BUILT-IN 4CHANNEL HIGH PERFORMANCE CLASS A/B AMPLIFIER (70W RMS)

OIS – OEM Impedance Simulation

The ZDA4.8 is equipped with OEM Impedance Simulation (OIS), ensuring compatibility with modern head units and amplifiers. By simulating speaker impedance, it maintains the functionality of your vehicle’s OEM head unit, preventing potential issues with plug-and-play installations.

Input Priority

The Input Priority feature ensures effortless integration with your vehicle’s OEM head unit. You can use low-level inputs or digital sources such as Bluetooth, Optical, or Coaxial, without losing vital system sounds like parking sensors, alerts, and radio signals. For instance, if your vehicle has a high-pass filter that limits bass output, you can bypass this limitation by streaming audio directly to the DSP via Bluetooth while maintaining full OEM functionality.

Key Features:

Every detail of the ZDA Series amplifiers is engineered for excellence:

Burr Brown OPs – Leveraging the same renowned technology as our ZQ series for superior audio precision.

Burr DAC PCM1681 – Delivering premium digital-to-analogue conversion for crystal-clear sound.

Bluetooth 5.0 – Seamless wireless connectivity with cutting-edge stability and performance.

Toshiba TDA Transistor Package – Power and efficiency perfectly combined.

Die-Cast Heatsink – Advanced cooling design for peak performance under pressure.

48kHz DSP Sampling Rate – Ensuring unmatched clarity and processing accuracy.

Gold PCB Design – A mark of Phoenix Gold’s commitment to quality and durability.

Molex Connectors – Reliable connections for a worry-free setup.

8-Channel DSP (All Models) – Unlock unlimited possibilities for customization.

Class A/B Design – Delivering natural, uncompromised sound without noisy fans.

Hardware Specifications

Product: ZDA4.8

Type: DSP Amplifier

Amplifier Class: A/B

Amplified Channels: 4

DSP Channels: 8

Frequency Response (-3dB): 15Hz ~ 23kHz

MAX Power Rating: 560W

RMS Power Rating (2Ω): N/A

RMS Power Rating (4Ω): 4 x 70W

RCA Voltage Output: 4V

DAC: Burr Brown PCM1681

DSP Resolution: 24 Bit

Sampling Rate: 48kHz

SNR (Analogue/Digital Input): -90dB

THD: 0.1%

Crosstalk: -60dB

Damping Factor: 120

High-Level Input: Yes

Auto Turn-On: Yes

Input Sensitivity (High-Level): 0.2V – 20V

Input Sensitivity (Low-Level): 0.2V – 5V

Operating Voltage: 9V – 16V

Start-Stop Compatible: Yes

Idle Current: 1.5A

Current Draw (MAX): 30A

Total Efficiency (4Ω): 60%

Power Terminal: 10mm²

Remote (Optional): ZDAWCT

Low-Level Outputs (RCA): 8

Analogue Inputs: 6 x High-Level / 2 x Low-Level

Digital Inputs: Bluetooth / Coaxial / USB / SPDIF

Remote Input: Yes

Remote Output: Yes

PC Connection Input: USB-B

APP Control (Coming Soon): Yes
